Experience top-notch precision with Quectel’s LC76G GNSS module, offering simultaneous reception of GPS, GLONASS, BDS, Galileo, and QZSS signals. Compatible with Quectel L76 and L76-LB modules, it facilitates smooth migration. Find it in SOS electronic warehouse selection for your IoT projects today.
PAVEL KOVÁČ SOS electronic Product Specialist More articles from the author
Multi GNSS module Quectel LC76G
This module even received the Product of the Year 2022 award from Electronic Products, which grants this prize for significant technological advancement, exceptionally innovative design, a balanced price-performance ratio, improved construction performance, and potential for designing new products.
You can find the high-performance GNSS module in the extensive range of Quectel GPS modules in SOS electronic stock.
Quectel LC76G – powerful and precise GNSS module with low power consumption
Compared with single constellation receivers, by enabling multiple GNSS constellations, the LC76G module increases the number of visible satellites, reduces the time needed for installation and improves positioning accuracy, especially when driving through densely populated urban areas.
Its integrated LNA provides high sensitivity and allows precise position detection, as well as fast signal tracking and acquisition and better performance even in challenging environments. By combining EASY™ (Embedded Assist System), an advanced AGNSS feature, with GLP* (GNSS Low Power) low-power mode, the LC76G achieves high performance with low power consumption and fully meets the industrial standards.
The EASY™ technology enables the module to automatically calculate and predict satellite orbits using ephemeris data (duration of up to 3 days) stored in internal RAM. As a result, the Quectel module quickly achieves position fix even at lower signal levels with low energy consumption. Additionally, with GLP technology, it can adaptively adjust the on/off time based on environmental conditions and movement to achieve a balance between the positioning accuracy and power consumption.
Thanks to its enhanced performance, the Quectel LC76G module is ideal for consumer and industrial applications. Its extremely low power consumption makes it a perfect solution for power-sensitive applications, such as portable devices.
Main features of Quectel LC76G module:
- multi-GNSS engine for GPS, GLONASS, Galileo, BDS and QZSS, ensuring fast and accurate fix in any environment,
- footprint compatible with L76 module,
- industry-leading sensitivity: -166 dBm during tracking and -147 dBm during acquisition,
- integrated LNA improves sensitivity,
- embedded multi-tone active interference canceller for anti-jamming,
- supported interfaces: UART and I2C,
- compact design: 10,1 mm × 9,7 mm × 2,4 mm,
- weight: 0,3 g,
- operating temperature –40 to +85 °C.
GNSS modules LC76GABMD and LC76GPAMD can be found in SOS electronic´s assortment as stock items, readily available for your projects.
