The SSM series from P-Duke of surge protection modules are now available from Luso Electronics.
They operate by clamping input surge voltages to a certain level to protect DC/DC converters and also makes them keep working when an input surge occurs.
They are designed for protecting DC/DC modules used for railway applications.
Throughout Europe, electronic equipment in railway applications is governed by two international standards. The general standard quoted is EN50155, however In the U.K. the standard that applies is RIA12 whilst these two standards are similar in most respects, the RIA12 standard also requires the equipment to be able to withstand specific power surges. The SSM series are specifically designed to meet this requirement
There are 3 devices in the family, one for low power circuits power range of 20W, then 2 others covering up to 150W and 300W. All cope with voltage input ranges of 43 to 160W.
We can arrange for samples for testing along with matched dc/dc modules for your rail application.
Features
■ Clamp Input Surge Voltage
■ Standards met RIA12 Surge Susceptibility & NF F 01-510 Surge Susceptibility
■ Input Range: 43-160 VDC
■ 385 VDC Maximum Peak Voltage
Contact our engineers or help in selecting the right module for your application.
