SV Microwave’s secure locking QuarterBack® RF cable assemblies utilize a quarter turn bayonet style coupling nut with a locking feature for standard SMP / SMPM interfaces and standard female and male bulkhead SMPM interfaces. All SV QuarterBack® products are ideal for high vibration and test applications that require a large number of mating cycles.
Features / Benefits:
- Quarter turn bayonet locking feature on standard SMPM interface
- Low VSWR through 40 GHz(SMP)/65 GHz (SMPM)
- Female cable connector options available for all flexible cable types .086” diameter and smaller
- Low insertion/extraction forces, compared to standard full detent SMP and SMPM, means less torque on board mount connector solder joints during mating and demating
- Spring loaded positive mating feature allows excellent electrical performance even in extreme vibration environments
- Low mating forces allow for more mating cycles without failure compared to full detent SMP and SMPM
Applications
- Bench-top testing (PCB mount, cable connectors and adapters)
- High vibration environments
- Applications requiring a high number of mating cycles
- Military and Commercial options available
