What is Dielectric Constant?
The dielectric constant (Dk) of a plastic or dielectric or insulating material can be defined as the ratio of the charge stored in an insulating material placed between two metallic plates to the charge that can be stored when the insulating material is replaced by vacuum or air. It is also called as electric permittivity or simply permittivity.
And, at times referred as relative permittivity, because it is measured relatively from the permittivity of free space (ε0).
Dielectric constant characterizes the ability of plastics to store electrical energy. Typical values of ε for dielectrics are:
https://omnexus.specialchem.com/polymer-properties/properties/dielectric-constant
A dielectric constant of 2 means an insulator will absorb twice more electrical charge than vacuum.
Applications include:
- Use of materials in the production of capacitors used in radios and other electrical equipment. Commonly used by circuit designers to compare different printed-circuit-board (PCB) materials.
Development of materials for energy storage applications.
For example, polymer-based dielectric composites are highly desirable for applications ranging from electronic packaging, embedded capacitors, to energy storage. These composites are highly flexible with a low process temperature and they exhibit a relatively high dielectric constant, low dielectric loss, high dielectric strength.
How to Calculate Dielectric Constant?
In other words, dielectric constant can also be defined as the ratio of the capacitance induced by two metallic plates with an insulator between them, to the capacitance of the same plates with air or a vacuum between them.
An insulating material with higher dielectric constant is needed when it is to be used in E&E applications where high capacitance is needed.
If a material were to be used for strictly insulating purposes, it would be better to have a lower dielectric constant.
Where:
C = capacitance using the material as the dielectric capacitor
C0 = capacitance using vacuum as the dielectric
ε0 = Permittivity of free space (8.85 x 10-12 F/m i.e. Farad per metre)
A = Area of the plate/sample cross section area
T = Thickness of the sample
Dielectric Constant Units: This electrical property is a dimensionless measure.
The most generally used standard tests to calculate dielectric constant for plastics are ASTM D2520, ASTM D150 or IEC 60250 (ofcourse there exist several other methods as well, but they are not discussed here).
The method includes:
A sample is placed between two metallic plates and capacitance is measured. A second run is measured without the specimen between the two electrodes. The ratio of these two values is the dielectric constant.
- The test can be conducted at different frequencies, often between the 10Hz and 2MHz range
The sample must be flat and larger than the 50mm (2 in) circular electrodes used for the measurement.
Polar Plastics Vs Non-polar Plastics
Dielectric properties of a polymer largely depend upon their structure. The structure determines whether a polymer is polar or non-polar and this in turn decided the electrical properties of the polymer.
- In polar polymers (PMMA, PVC, Nylon, PC etc.), dipoles are created due to imbalance in the distribution of electrons. These dipoles tend to align in the presence of electric field. Hence, this creates dipole polarization of the material making these materials only moderately good as insulators.
- While non-polar polymers (PTFE, PP, PE, PS) have symmetrical molecules and are truly covalent. There are no polar dipoles present in them and hence in presence of electric field does not align the dipoles. However, slight electron polarization occurs due to the movement of electrons in the direction of electric field, which is effectively instantaneous. These polymers have high resistivities and low dielectric constant.
Polar plastics have a tendency to absorb moisture from the atmosphere. Presence of moisture raises the dielectric constant and lowers the resistivity. With rise in temperature, there is faster movement of polymer chains and fast alignment of dipoles. This invariably raises the dielectric constant values for polar plastics.
Non-polar plastics are not affected by moisture and rise in temperature.
Factors Influencing Dielectric Constant
- Frequency – Dielectric constant decreases abruptly as frequency increases
Moisture &Temperature
Voltage
Structure & morphology (see polar plastics vs non-polar plastics)
Presence of other materials in the plastic
Weathering and Deterioration
