Two-fold efficiency improvement – unique combination of low conduction losses of 1.85 V (Vcesat) and lowest switching losses.
The 1200 V IGBT generation TRENCHSTOP™ IGBT 6 is released in 2 product families – low conduction losses optimized S6 series and improved switching losses H6 series.
TRENCHSTOP™ IGBT6 S6 series features low conduction losses of 1.85 V (VCEsat) combined with low switching losses of the Highspeed3 H3 series.
TRENCHSTOP™ IGBT6 H6 series is optimized for low switching losses, provides ~15% lower total switching losses when compared to predecessor generation H3.
The IGBT6 devices can be used as direct replacement for the Highspeed3 H3 series without any changes of the design. Such plug & play replacement of H3 with new S6 IGBT may benefit up to 0.2% efficiency improvement.
