Rohde & Schwarz collaborates with Broadcom on test solution for next generation 6-GHz Wi-Fi devices


The R&S CMP180 radio communication tester has been successfully validated for Broadcom’s Wi-Fi 6E chipsets. OEMs and ODMs of wireless devices are now able to bring their first next generation 6-GHz products to the market.



The R&S CMP180 has been successfully validated for Broadcom’s Wi-Fi 6E chipsets.

Rohde & Schwarz, a leading supplier of test and measurement equipment for wireless applications, today announced the availability of test solutions for the Broadcom® 6GHz Wi-Fi 6E chipsets, the industry’s first to

operate in the 6 GHz band. In collaboration with Broadcom Inc., Rohde & Schwarz has successfully verified the new R&S CMP180 next generation wireless device test platform, which is especially suitable for R&D as

well as production. OEMs and ODMs of wireless equipment, who integrate Broadcom Wi-Fi 6E chipsets, now have access to the right test solution for R&D, quality control, and production prototyping.

The IEEE 802.11ax amendment (Wi-Fi 6/6E), operating in the 2.4 GHz, 5 GHz and 6 GHz bands, intends to improve WLAN system efficiency, especially the throughput per station in dense signal environments and

outdoor environments. With up to 1.2 GHz of Wi-Fi spectrum available for unlicensed use in the 6-GHz band, Wi-Fi 6E can access up to seven 160-MHz channels to support various bandwidth-driven use cases.

These technologies pose challenges for test and measurement equipment. For example, the 1024QAM modulation requires signal generation capabilities which transmit reference signals with very low distortion

over a bandwidth of up to 160 MHz and the required analysis bandwidth. The R&S CMP180 has been qualified for characterizing Broadcom 6 GHz Wi-Fi chipsets at the RF level for tests such as error vector

magnitude (EVM), timing measurements and spectrum emission compliance. Rohde & Schwarz also provides a Wireless Manufacturing software for Broadcom 6 GHz Wi-Fi chipsets and service solutions to

OEMs and ODMs.



Christoph Pointner, Senior Vice President Mobile Radio Testers at Rohde & Schwarz, says: “We are happy to provide tailored test solutions that help Broadcom’s customers bring the newest Wi-Fi technology to the

market. The joint efforts with Broadcom for Wi-Fi 6E also provide a solid foundation to enhance our test solution for next generation Wi-Fi 7, which will leverage on the 6 GHz band to deliver higher performance

and throughput.”



Gabriel Desjardins, Director of Product Marketing in the Wireless Communications & Connectivity Division at Broadcom Inc., says: “We continue to collaborate with Rohde & Schwarz in developing 6 GHz Wi-Fi test

systems. The availability of these systems has enabled our customers and partners to accelerate deployment of 6GHz Wi-Fi.

The R&S CMP180 radio communication tester is a future-proof, non-signaling testing solution for wireless devices in research and development, validation and production. Together with advanced frequency,

1/2 bandwidth and RF capabilities, it enables testing of new wireless technologies such as Wi-Fi 6E, Wi-Fi 7 and many more. Additionally, the doubled number of analyzers (2xVSA), generators (2xVSG) and RF ports (2×8)

enable simultaneous measurements of technologies and devices in a VSA/VSG single-box tester.



At CES Las Vegas from January 5 to January 8, 2022, Rohde & Schwarz will showcase a Wi-Fi 6E test setup featuring the R&S CMP180 and the BCM4389 Wi-Fi 6E device from Broadcom.
