New Product Alert: SMA Cable Assemblies for LMR 195 & 240 Cable

Amphenol RF offers a line of SMA fixed length cable
assemblies on LMR-195 and LMR-240 cables. This full
Amphenol solution combines precision machined Amphenol
RF SMA connectors with high performing LMR cables
developed by Times Microwave, an Amphenol company.
These pre-configured cable assemblies are designed to offer
a lower loss option with superior electrical performance to
standard cables.

The LMR Cable Assemblies operate between DC to 6 GHz
and are ideal for wireless communications systems and high
performing applications such as base stations, antennas, and
other telecommunication devices. The cable is constructed
with a black polyethylene jacket, closed cell foam poly
dielectric, and bonded tape conductor. All of these
components work together to make the LMR cable more
rugged compared to other braided cables. The 50 Ohm SMA
connectors feature brass construction with gold plating.

These new assemblies are offered in straight plug to straight
plug, straight plug to right-angle plug, straight plug to
bulkhead jack and right-angle to right-angle plug
configurations. They are also available in standard imperial
lengths of 6, 12, 18, 24, 36, and 48 inches, along with metric
lengths of 0.25, 0.50, 0.75, and 1 meter. Custom lengths are
available upon request.

Features and Benefits
• RF Performance DC to 6 GHz
• Lower loss option with superior performance
• More rugged than other braided cables
• Cellular/Broadband Amplifiers
• Microwave Filters
• Wireless Infrastructure
• Remote Sensing and Metering
• GPS Antennas
• Radar Systems
• High Speed Routers and Switches
• Automated Test Equipment

Amphenol RF
Four Old Newtown Road
Danbury, CT 06810
For more information visit
or call 800.627.7100
